Sintered Felt Porous Metal Filter Element Forming a Stable Integral Porous Body with Many Advantages

Description

Sintered felt is a porous metal filter material manufactured by laying metal fibers into a non-woven felt structure and then sintering under high temperature and vacuum conditions. The metal fibers are metallurgically bonded at contact points, forming a stable, integral porous body without adhesives. Common raw materials include stainless steel fiber, Hastelloy, Monel, Inconel, and titanium fibers.

Key Advantages

High mechanical strength & structural stability

Integrated sintered structure, resistant to pressure impact, not easy to deform or fiber shedding; can withstand high differential pressure.

Controllable & uniform pore size

Pore distribution is consistent, with precise filtration rating from sub-micron to tens of microns, achieving stable particle retention performance.

Excellent high temperature & corrosion resistance

Suitable for high-temperature working conditions up to 400–600°C. Different alloy grades resist acid, alkali, organic solvents and oxidation.

Good permeability & high dirt holding capacity

Three-dimensional interlaced fiber structure provides large filtration area and high contaminant loading capacity, extending service life.

Cleanable & reusable

Can be cleaned by back-flushing, ultrasonic cleaning or chemical washing for repeated use, lowering operating cost.

Self-supporting & easy processing

Can be fabricated into filter tubes, discs, sheets, cones and other customized shapes for various filter assemblies.
