Oil Condition Sensor and Display for Hydraulic Systems

The LPC-Z Online Oil Contamination & Water Content Detector focuses on detecting particulate contamination levels and water content in oils. For particulate contamination detection, it uses a semiconductor laser and operates on the classic light obscuration principle to measure particle diameter (µm) and particle size distribution in real-time. For water content (trace moisture) detection, it employs a moisture sensor to measure two physical quantities in real-time: water activity and temperature in the oil.

The LPC-Z utilizes an advanced, patented full-spectrum method.By analyzing the differences in optical characteristics between bubbles and particles, it accurately identifies and eliminates bubble interference, thereby precisely calculating the actual particle count in the oil, providing users with more reliable oil contamination data.

Basic Parameters：
Weight ：538g		Dimension (mm)：105length×89 width×64 height
Max Operating Pressure：1Mpa		Channels: 5 or 6 channels, adaptive standard settings
Oil Temperature: -10 ~ 80°C		Operating Temperature: -20 ~ 60°C
Operating Humidity: 20 ~ 85%RH		Storage Temperature: -40 ~ 85°C
Storage Humidity: 20 ~ 85%RH		Power Supply: 10 ~ 26V DC
DC Ripple: <100mVp-p		Output Interface: RS232 / RS485
Applicable Oil Types: Hydraulic oil, lubricating oil, insulating oil, turbine oil, etc.
Power Consumption: 10V:212mA  15V:137mA  20V:97mA  25V:82mA
Seal Material: NBR (Nitrile Rubber)		Calibration Cycle: One year
Pipe Connection: M10×1mm (standard)		Electrical Connector: YC9-8
Flow Rate Range: 50 ~ 200 mL/min		Alarm Method: Panel LED alarm, fault code upload
Contamination Detection Specifications (Particle Sizes):
* 5µm~15µm、15µm~25 µm、25 µm~50 µm、50 µm~100µm、＞100µm； * ≥4µm(c)、≥6µm(c)、≥14µm(c)、≥21 µm(c)、≥38 µm(c)、≥70 µm(c)
Detection Standards: ISO 4406, NAS 1638, GJB 420B, Customizable
Repeatability: ±0.5 ISO grade	Measurement Accuracy: ±1 grade
Water Content Detection Specifications:
Measurement Range: Water Activity (0 ~ 100)%RH, 0 ~ 1000 PPM
Measurement Accuracy: Water Activity ≤ ± 3%@(0 ~ 80% RH)(0℃ ~ 60℃) % FS
