Product Details
Description
1st stage: oil suction filter, located at the oil suction port. As a coarse filter, it protects the oil pump and extends the service life of the main filter.
2nd stage: Pre-filter, located in the upstream of the coalescence filter.
3rd stage: Coalescence filter, to make the water in the oil condense and sink.
4th stage: Separate filter, to further block the tiny drops of water in the oil,achieving the function of efficient separation.
5th stage: Fine filter, clean the oil again to a very high clean level before the oil outlet.
Model | AOP-D25 | AOP-D50 | AOP-D100 | AOP-D150 | AOP-D200 | AOP-D400 |
Flow rate(L/M) | 25 | 50 | 100 | 150 | 200 | 400 |
Pressure(Mpa) | 0.6 | |||||
Pressure loss(Mpa) | ≤0.01 | |||||
Water contents | ≤100 ppm | |||||
Coarse filter precision(um) | 100 | |||||
1st Fine filter precision(um) | 10、20 | |||||
2nd Fine filter precision(um) | 3、5 | |||||
DP(Mpa) | 0.2 | |||||
Temperature | 25-80°C | |||||
Viscosity(cSt) | 10-120 | |||||
Voltage | AC380V 3 phase 50HZ | |||||
Motor Power(kw) | 0.75 | 1.1 | 2.2 | 4 | 5.5 | 13 |
Weight(kgs) | 150 | 200 | 300 | 520 | 860 | 2860 |
