Product Details
The hydraulic filter element are used in hydraulic system to filter solid particles and colloidal substances in the working medium,effectively contol the pollution degree of the working medium ,so as to ensure the normal operation of equipment.
This series filter element are made of international standard precision glass fiber material, and fixed by the support network, , filter precision grade can be freely selected , suitable for different pressure oil suction system, oil return system, high and low pressure system, low maintenance cost, long service life.
| O.D. | 6.0" |
|---|---|
| I.D. Top | 2.62" |
| I.D. Bottom | 2.62" |
| Length Overall | 16.0" |
| Construction Type | Double Open End, Microglass |
| Efficiency | 3 Micron; B3 = 200, B4.5 = 1000 |
| Gasket Material | Buna-N |
| Wire Support | Yes |
| Max Operating Pressure | 150 PSID Collapse |
| Max Temp | 248 Degress F |
| Weight Each | 7 |
| Carton Qty | 6 |
| Condition | New |
